5.0 Inch TFT LCD Module 800×480 RGB Interface 600 Nits High Brightness Industrial LCD Display Module

Communication interface : 24-bit RGB Parallel, DE/SYNC mode selectable, 50-pin FPC

Model Number : YNO0500NJR-S1

Supply Ability : 10000pieces

Price : $6.41-8.01/pieces

Display : 5.0" TFT-LCD, 800×480, 16.7M colors

Operating Temperature : -20°C ~ +70°C

Place of Origin : Guangdong, China

Delivery Time : 14-60days

Backlight Type : 18 pcs White LED

MOQ : 500

Packaging Details : 20*15*5

Brand Name : YZY

Payment Terms : T/T

Contact Now

5.0 Inch TFT LCD Module 800×480 RGB Interface 600 Nits High Brightness Industrial Display (YNO0500NJR-S1)

5.0 Inch TFT LCD Module 800×480 RGB Interface 600 Nits High Brightness Industrial LCD Display Module

5.0" TFT LCD Module Highlights:

*Model: YNO0500NJR-S1 (SH050QGH65-05187L-01-88)

*5.0 inch display, 800×480 WVGA resolution

*600 nits high brightness, 350:1 contrast ratio

*24-bit RGB parallel interface, 50-pin FPC

*16.7M colors, wide viewing angle TFT panel

*Industrial temp range: -20°C to +70°C

*RoHS compliant, 12-month warranty

YNO0500NJR-S1 — 5.0 Inch TFT LCD Module Specifications
Parameter	Value
Customer Model No.	YNO0500NJR-S1
Module No. / Part Number	SH050QGH65-05187L-01-88
LCD Type	a-Si TFT-LCD, Transmissive
Display Size	5.0 Inch Diagonal
Resolution	800 × 480 dots (WVGA)
Display Colors	16.7M (24-bit RGB, 18-bit compatible)
Active Area (W × H)	108.00 × 64.80 mm
Outline Dimension (W × H × T)	120.70 × 75.80 × 3.5 mm
Brightness (Typ.)	600 cd/m² (nits)
Contrast Ratio (Typ.)	350 : 1
Luminance Uniformity (Typ.)	80%
Viewing Angle (Cr≥10)	Left/Right/Up: 75°, Down: 50°
Response Time (Typ.)	20 ms (Tr+Tf)
NTSC Color Gamut	50%
Interface Type	24-bit RGB Parallel (DE/SYNC mode), 50-pin FPC
Logic Power Supply (VCC)	3.3V (Typ.), 3.0V ~ 3.6V
Backlight Type	18 pcs White LED (6-chip series × 3 parallel)
Backlight Voltage (Typ.)	19.2V
Backlight Current (Typ.)	60 mA (20mA per string)
Operating Temperature	-20°C ~ +70°C
Storage Temperature	-30°C ~ +80°C
Special Functions	Built-in dithering, BIST pattern, SHLR/UPDN flip control
Compliance	RoHS, REACH, CE

Why Choose YZY:

*15 years of LCD screen production experience

*Strong engineer team and 24 hours online service

*Products are RoHS, REACH and CE certified

*Products have a 12-month warranty period

*High quality & low price, high reliability, long-term supply

*Customization available: brightness, interface, touch panel

Frequently Asked Questions (FAQ)

Q1: What is the lead time for the YNO0500NJR-S1 5-inch TFT LCD module?
A: Standard samples ship within 3-5 working days. Bulk orders typically take 15-25 working days depending on quantity and customization requirements.

Q2: Can this 800×480 TFT display support a capacitive or resistive touch panel?
A: Yes. We can add a capacitive (PCAP) or resistive (RTP) touch panel overlay based on your project needs. Please contact our sales team for touch integration options.

Q3: Is the 50-pin RGB interface compatible with my MCU/processor?
A: This module uses a standard 24-bit RGB parallel interface with DE/SYNC mode select. It is compatible with most ARM, STM32, and embedded processors that support RGB output. We provide pinout definition and driving guidance.

Q4: What applications is this 5.0 inch TFT LCD module suitable for?
A: Ideal for industrial control panels, HMI, smart home devices, medical equipment, automotive displays, POS terminals, handheld instruments, and IoT devices requiring a compact high-brightness display.

Q5: Do you offer customization for brightness, viewing angle, or FPC length?
A: Yes. We support customized brightness (up to 1000+ nits), viewing direction, FPC cable length, backlight voltage, and cover glass (AG/AR/AF). MOQ applies for custom versions.

Q6: What is the warranty and after-sales policy?
A: All our TFT LCD modules come with a 12-month warranty. We offer technical support throughout the product lifecycle and guarantee long-term supply for ongoing production orders.
